According to customer needs, in the process of fast-moving products, scribe type non-contact, non-stop, high-quality laser printing. As the laser marking is the surface layer of biomass gasification, so writing a permanent marking out non-erasable, may play a security anti-changing function. High-speed response system that can meet the needs of various types of fast production line is widely used in brewing, pharmaceutical, tobacco monopoly, food and beverage, household chemicals, electronics, fabrication, timber and other industries. Applicable to all types of paper, all kinds of plastic material, the metallic paint and other packaging materials.

With the continuous development of electronic technology, laser and computer technology together organically, as long as the computer user programming, you can achieve laser marking output. It can also be played simultaneously on several materials or punch on irregular surfaces clear identity, with "a dozen double standard" or "straddle logo" unique effect, difficult to imitate. The laser beam can be formed very fine, the surface of the thin material can reach 0.1 mm in width, precision machining and security to create a wide space. Not only can play a complex text, graphics, images, translucent keys, logo design, barcodes, two-dimensional code, serial number, autograph ...... and so on, any display on the screen graphics and text can be specified immediately hit material surface. Laser marking can also improve the appearance of the image and name brand products and enhance market competitiveness.

Technical parameters:

★ Laser power : 10W/30W/50W
★ Control System: High quality commercial aircraft , LMC1 laser control board , EzCad2.0 control software
★ Marking range: standard 110 × 100mm ( optional 70 × 70mm 140 × 140mm 210 × 210mm)
★ lines: According to the information needed to set an arbitrary number of rows in the range of marking
★ Marking speed : 0 to 200 m / min ( depending on marking content, products, materials, and other features )
★ Repeat accuracy : ± 0.01mm
★ Laser wavelength : 10.6um
★ Minimum line width : 0.15mm
★ Total power : ≤ 1KW
★ character size :0.4-70mm digit height
★ marking methods : flying or static marking marking
★ Marking contents : any text, graphics , automatic serial numbers , numbers and characters combined automatic coding , production date , expiry date, batch number , logistics code , data and other communications
★ support font : TrueType ( double ) font , single font (JSF), bitmap fonts (DMF), one-dimensional and two-dimensional bar code barcode hundreds of laser marking , special fonts and font editor dedicated independent according to customer needs
★ Power supply : AC220V ,50-60Hz
★ Cooling: Air Cooled
★ ambient temperature :5-45 ℃
★ Relative humidity : ≤ 80% non-condensing
★ electromagnetic environment : the computer can work
